Complete Guide to Flute Types in Corrugated Boxes
Understanding A, B, C, E, F flutes and when to use each type. Make informed decisions about flute selection for your packaging needs.
The flute is the wavy middle layer of corrugated board that provides cushioning and strength. Choosing the right flute type is critical for packaging performance.
What is a Flute?
The flute is the corrugated (wavy) paper sandwiched between liner boards. It creates air pockets that provide:
- Cushioning against impacts
- Stacking strength
- Insulation properties
- Printability surface
Common Flute Types
A-Flute (Large Flute)
- Height: 4.8mm
- Flutes per meter: 105-125
- Best for: Heavy items, cushioning, fragile products
- Characteristics: Maximum cushioning, good stacking strength, bulkier boxes
Use when: Products need maximum protection, weight >15kg, long-distance shipping
B-Flute (Small Flute)
- Height: 2.5mm
- Flutes per meter: 150-185
- Best for: Die-cutting, printing, retail displays
- Characteristics: Flat surface for printing, compact, good crush resistance
Use when: Printing quality matters, smaller products, point-of-sale displays
C-Flute (Medium Flute)
- Height: 3.6mm
- Flutes per meter: 120-145
- Best for: General shipping, balance of properties
- Characteristics: Most versatile, good cushioning + printability
Use when: General-purpose shipping, moderate protection needs, versatility required
E-Flute (Micro Flute)
- Height: 1.5mm
- Flutes per meter: 290-320
- Best for: Primary packaging, retail boxes, cosmetics
- Characteristics: Excellent print surface, compact, lightweight
Use when: High-quality printing needed, lightweight products, premium packaging
F-Flute (Ultra-Thin)
- Height: 0.8mm
- Flutes per meter: 400-420
- Best for: Fast food containers, jewelry boxes
- Characteristics: Thinnest flute, very smooth surface
Use when: Food packaging, luxury small items, maximum printability
Double-Wall Combinations
BC-Flute
- Height: 6.5mm
- Combines B-flute and C-flute
- Maximum strength for heavy items
EB-Flute
- Height: 4.0mm
- Combines E-flute and B-flute
- Good printing + strength balance
Flute Selection Guide
| Product Type | Recommended Flute | Reason |
|---|---|---|
| Electronics <2kg | E or B | Good print, compact |
| Electronics 2-10kg | B or C | Balance of properties |
| Electronics >10kg | BC or double-wall | Maximum protection |
| Food packaging | E or F | Food-safe, printable |
| Fresh produce | C with ventilation | Cushioning, airflow |
| Furniture parts | A or BC | Heavy-duty protection |
| Cosmetics | E | Premium appearance |
| Retail displays | B | Die-cut friendly |
Cost Comparison
Per square meter (approximate):
- E-Flute: ₹25-30
- B-Flute: ₹28-35
- C-Flute: ₹32-40
- A-Flute: ₹35-45
- BC-Flute: ₹55-70
Note: Larger flutes use more paper but fewer flutes per meter. Total cost depends on paper GSM and application.
Performance Characteristics
Cushioning (Drop Protection)
A-Flute > C-Flute > B-Flute > E-Flute > F-Flute
Stacking Strength
BC-Flute > A-Flute > C-Flute > B-Flute > E-Flute
Print Quality
F-Flute > E-Flute > B-Flute > C-Flute > A-Flute
Material Efficiency
F-Flute > E-Flute > B-Flute > C-Flute > A-Flute
Key Takeaways
- C-Flute is most versatile for general shipping
- E-Flute for premium printing and retail packaging
- B-Flute for die-cutting and displays
- A-Flute or BC for heavy-duty applications
- Consider product weight, fragility, and presentation needs
- Double-wall for items >15kg or long-distance shipping
